VarioCAM
Features
  • Microbolometer camera with up to (1,024 × 768) IR pixels
  • Optomechanical MicroScan with up to (2,048 × 1,536) IR pixels
  • Frame rate of up to 240 Hz, GigE-Vision interface
  • Integrated light-sensitive digital 8 MP camera
  • 5.6" colour TFT display with (1,280 × 800) pixels
  • Laser rangefinder and GPS sensor
  • Wireless camera control and data acquisition via WLAN
  • Made in Germany



VarioCAM® HD from Jenoptik

Transmission

Photovoltaic power plant

Specifications
Spectral range (7.5 ... 14) μm
Detector Uncooled Microbolometer Focal Plane Array
Detector format (IR pixels) (1,024 × 768) with built-in opto-mechanical high-precision scan unit (2,048 × 1,536)*
(640 × 480) with built-in opto-mechanical high-precision scan unit (1,280 × 960)*
Temperature measuring range (-40 ... 1,200) °C, > 2,000 °C*
Measurement accuracy ± 1 °C or ± 1 %*, otherwise ± 1.5 °C or ± 1.5 %
Temperature resolution @ 30 °C Better than 0.03 K*, otherwise better than 0.05 K
Frame rate Fullframe: 30 Hz (1,024 × 768), subframe formats*: 60 Hz (640 × 480) / 120 Hz (384 × 288) / 240 Hz (1,024 × 96)
Fullframe: 60 Hz (640 × 480), subframe formats*: 120 Hz (384 × 288) / 240 Hz (640 × 120)
Image storage SDHC-card, GigE-Vision up to 240 Hz, internal real-time storage
Lens mount Bayonet to comfortably switch objectives, automatic objective detection and data transfer
Focus Motor-driven, automatic or manual, accurately adjustable, laser-supported autofocus
Zoom Up to 32x digital, stepless
Digital colour video camera 8 Megapixels, with a LED video light, vision mixer and cross-fade feature
Dynamic range 16 bit
Interfaces GigE-Vision, DVI-D, C-Video, RS232, Trigger, Analog output*, Digital I / O*,WLAN, USB 2.0, Bluetooth, GPS
Tripod adapter 1/4 " photo thread
Power supply Lithium-Ion battery (quick rechargeable, with status display), AC adapter
Laser range finder* Red semiconductor laser, laser safety class 2, range up to 70 m
Display 5.6 " colour TFT display (1,280 × 800) pixels, daylight suited
Colour viewfinder* Tiltable colour viewfinder with diopter compensation
Single-handed operation Intuitive operation with ergonomically arranged function keys and multifunctional joystick,
programmable keys
Storage and operation temperature (-40 ... 70) °C, (-25 ... 50) °C
Protection degree IP54, IEC 529
Impact strength/vibration resistance in operation 25 G (IEC 68 - 2 - 29), 2 G (IEC 68 - 2 - 6)
Dimensions, weight (210 × 125 × 55) mm, 1.7 kg
Automatic functions Autofocus, permanent autofocus, automatic distance indicator, distance-dependent calculation of permitted pixel size, Autoimage, Autolevel, Min./Max. temperature alarm: visual/acoustic, alarm triggered image storage
Measurement functions 8 free choosable, movable measurement fields/-points, automatic hot/cold spot display: global and internal defined measurement fields, differential temperature measurement: temporally/locally, temperature profile, histogram, differential image, isotherms display
Further functions EverSharp function (multifocus), shutter-free operation, temperature alarm, image merging, synchronous display of thermal and visual image in real-time
Analysis and evaluation software* IRBIS® 3, IRBIS® 3 professional, IRBIS® 3 view, IRBIS® 3 plus, IRBIS® 3 remote HD, IRBIS® 3 online, IRBIS® 3 process, IRBIS® 3 active, IRBIS® 3 mosaic, IRBIS® 3 vision, FORNAX 2.0
